Linka 51.2V 560AH /628AH /840AH /942AH LiFePO4 Battery With Movable Rotating Wheels, Powerwall Solution for Home Energy Storage
Linka 51.2V 560AH /628AH /840AH /942AH LiFePO4 Battery With Movable Rotating Wheels, Powerwall Solution for Home Energy Storage - Image 2
Linka 51.2V 560AH /628AH /840AH /942AH LiFePO4 Battery With Movable Rotating Wheels, Powerwall Solution for Home Energy Storage - Image 3
Linka 51.2V 560AH /628AH /840AH /942AH LiFePO4 Battery With Movable Rotating Wheels, Powerwall Solution for Home Energy Storage - Image 4
Linka 51.2V 560AH /628AH /840AH /942AH LiFePO4 Battery With Movable Rotating Wheels, Powerwall Solution for Home Energy Storage - Image 5
Linka 51.2V 560AH /628AH /840AH /942AH LiFePO4 Battery With Movable Rotating Wheels, Powerwall Solution for Home Energy Storage - Image 6

Linka 51.2V 560AH /628AH /840AH /942AH LiFePO4 Battery With Movable Rotating Wheels, Powerwall Solution for Home Energy Storage

  • High life, high cycle, LiFePO4 cell
  • 6000 times 10 years long service life
  • Thermostatic control, longer life
  • Easy Installation, Stackable with flexible brackets
  • Module Design, Flexible expansion
  • Flexible modular system
  • High-efficient energy storage battery Safe & reliable performance with LiFePO4 cell
  • The battery has a long life cycle Intelligent Monitor System
SKU: LK-17-005 Category:

Description

Product Introduction

  • Household energy storage products are designed for residential and small and medium-sized energy storage applications. This system integrates three core components: high-quality A-grade LiFePO4 cells, an intelligent battery management system, and a robust and aesthetically pleasing protective casing.
  • It features small size, high energy and high safety. This product features a 3.5-inch touchscreen interface and offers dual connection options: Bluetooth pairing enables real-time parameter monitoring and configuration through a dedicated mobile application, while router connection allows for remote system management via network access. Users can increase energy by adding multiple batteries in parallel to meet the growing power demand.



Application

  • Solar Storage
  • Household
  • Electricity
  • Nomadic farm
  • Central office



Parameter

Model 51.2V-560AH 51.2V-628AH 51.2V-840AH 51.2V-942AH
Battery LiFePO4 LiFePO4 LiFePO4 LiFePO4
Nominal Voltage 51.2V 51.2V 51.2V 51.2V
Nominal capacity 560AH 628AH 840AH 942AH
Nominal Energy 28.67kWh 32.15kWh 43.01kWh 48.23kWh
Recommended Charge Current ≤150A ≤150A ≤150A ≤150A
Maximum Continuous Discharge Current ≤200A ≤300A ≤200A ≤300A ≤200A ≤300A ≤200A ≤300A
Recommended maximum load power ≤8kw ≤12kw ≤8kw ≤12kw ≤8kw ≤12kw ≤8kw ≤12kw
Ultimate Maximum load power ≤10kw ≤15kw ≤10kw ≤15kw ≤10kw ≤15kw ≤10kw ≤15kw
Dimension (L*W *H) 720*490*815mm 1010*435*935mm
Approx. weight 255KG 350KG
Enclosure Protection IP21
Communication RS485/CAN
Recommended Charge Voltage 57.6V
BMS charge cut-off voltage 58.4V
BMS charge cut-off release voltage ≤57.6V
Balancing voltage ≥52.8V
Balancing open voltage ≥52.8V
Recommended Low Voltage Disconnect ≤45V
BMS Discharge cut-off voltage ≤40V
BMS Discharge cut-off release voltage ≥46V
Discharge Temperature -4 ~ 131 ºF (-20 ~ 55 ºC)
Charge Temperature -4 ~ 113 ºF (0 ~ 45 ºC)
Storage Temperature 23 ~ 95 ºF (-5 ~ 35 ºC)
BMS High Temperature cut-off 149 ºF (65 ºC)
Reconnect Temperature 131 ºF (55 ºC)
Resistance ≤50 mΩ @ 50% SOC
Actual volumetric efficiency ≥100%Nominal Energy
Maximum continuous Discharge current ≥100% Nominal Energy
Certifications UN38.3、  MSDS (battery)、  UL1642 & IEC62133 (cells)
Shipping classification UN 3480, CLASS 9
Compatible inverter s PYLON/Gro watt/vol tronic/Lux power tek/wow/schneider/D eye/vic tron/Schneider
sor otec/SMA/Good we/STUD ER/MUST/GIN LONG/s energy/T BB/MEGA REV O/AISWEI
More brands can contact our sales staff to provide inverter names for customization
Cycle life 6000 Cycles(25℃,100%DOD) for effectively lower total of ownership cost
Service life 10 years
